Focused transducers
Focused ultrasonic transducers are the perfect choice for long ranges.
Here we add a metal ring to the piezoceramic and matching material disk structure.
Key data:
- Well-focused sound beam
- Small beam width
- Maximum sound paths
- High quality with high echo voltage
- Slightly longer decay time
- Narrowest frequency bandwidth
Our tip:
We produce focused ultrasonic transducers in robust metal housings as standard.
Focused transducers
Focused ultrasonic transducers are the perfect choice for long ranges.
We add a metal ring to the piezoceramic and matching disk structure.
Key data:
- Well-focused sound beam
- Small beam width
- Maximum sound paths
- High quality with high echo voltage
- Slightly longer decay time
- Narrowest frequency bandwidth
Our tip:
We produce focused ultrasonic transducers in robust metal housings as standard.
Advantages of our focused transducers
Focused transducers from SECO Sensor are specially tailored to the requirements of industrial applications and offer numerous advantages:
Largest range
Well-focused sound beam and high echo voltage for maximum sound distances
Smallest beam width
Smallest beam width for reliable and wide measurements
High echo voltage
High quality with strong signal as the perfect choice for large operating ranges
Narrow frequency bandwidth
for stronger signals, high accuracy and less interference
Robust construction
Mounting in robust metal housing for use in harsh environmental conditions
Whether individual or standard – we will be happy to advise you.
We also offer proven standard transducers or customizable transducer solutions that are individually tailored to your requirements in the field of focused transducers. SECO Sensor develops, produces and supplies ultrasonic transducers, especially where robust, maintenance-free and high-quality components are required.
Contact us today to find out more about our focused transducers!
Martin Röder
Product manager
Why ultrasonic transducers from SECO Sensor?
High-quality materials
It starts with our tried-and-tested material concept consisting of specially developed and in-house produced acoustic matching materials, self-assembled strands and high-quality potting compounds according to our own recipes. These innovative materials enable fine, individual tuning of the electro-acoustic properties of the transducer and ensure optimum sound transmission.
Another key to the outstanding quality of our ultrasonic transducers is the use of premium PZT ceramics (piezoelectric materials) – preferably from regional suppliers. These advanced ceramics are crucial for the effectiveness of the ultrasonic transducers, as they have high quality and low fluctuations. This guarantees that sensors with our transducers work reliably and accurately even in the most demanding measurement environments.
The combination of material and experience
Our expertise is not limited to materials. We have decades of experience in the development and series production of ultrasonic transducers for air and gases. The know-how of our product managers and our production staff enables us to offer customized solutions for a wide range of applications. Whether you need ultrasonic transducers for distance measurement, double sheet control or wind measurement – we have the experience and the technology to support you with your individual measurement task.
Our customers know that the quality of the ultrasonic transducer is a decisive factor for the overall quality of their sensors. With ultrasonic transducers from SECO Sensor, you can be sure that your sensors will deliver reliable and accurate measurement results even under extreme environmental conditions or in challenging installation situations.
High-quality materials – for outstanding quality
Our aim is to build high-quality, durable and robust ultrasonic transducers with outstanding electro-acoustic properties. We pay particular attention to the four main components: piezo disk, matching material, potting compound and stranded wire. With many years of experience, we manufacture our own material for this or source it from reliable suppliers with the highest quality standards. In this way, we ensure that our customers receive only the best products – with every ultrasonic transducer that leaves our company.
Piezo disk
We source our piezoceramic transducers from selected suppliers with above-average quality standards, primarily from Germany. This is characterized by a high degree of efficiency as well as minimal geometric and electrical tolerances.
Matching material
We produce our matching material in-house according to our own proven recipes. To achieve the best possible results, we use a particularly light, pressure-resistant epoxy filled with hollow glass beads, which is subject to only minimal fluctuations compared to products from external suppliers.
Potting compound
Potting with our specially formulated, soft-elastic polyurethane foams gives your transducer both mechanical stability and excellent structure-borne sound suppression – especially in cold conditions. We use customized potting compound recipes to achieve optimum acoustic parameters, adapted to your requirements.
Stranded wire
We mainly assemble our coaxial, Teflon and PVC strands ourselves. This enables us to ensure the highest quality and implement customer-specific adaptations quickly and easily. Short delivery times are also possible for special sizes. Our direct access to the production process allows us to carry out close checks and ensure consistently high strand quality, e.g. in accordance with IPC-A-610, class 3.
Our experienced team – for your success
For us, our employees are more than just anonymous cogwheels. Our corporate culture is characterized by flat hierarchies and open, respectful communication. Together, we manufacture ultrasonic transducers of outstanding quality with great expertise. Your satisfaction is our goal – we work on it every day.
For us, this means
Customer-oriented support
- Individual support
- Close cooperation
- Constructive communication
- Personal contact person
- Reliable accessibility
Qualified team of experts
- Comprehensive support for your product
- All-round technical support
- Excellently trained experts
- Development of new solutions
- Customization, small quantities
Machine-supported manual work
- Narrowly tolerated production parameters
- High process stability
- comprehensively trained employees
- Final test on 100% of the transducers
- ISO 9001:2015 & ISO14001:2015
“We develop an innovative solution for almost every measuring task. Individual support and intensive discussions with our customers are particularly important to us. From the initial idea to prototype construction and series production, we rely on a close exchange of ideas and qualified technical advice.”
“For offshore systems, we also equip our anemometer transducers with an optional scratch-resistant, water and dirt-repellent protective coating. This prevents droplet formation on the surface and icing of the front surface.”
“SECO Sensor is increasing its presence on social media. Contact and networking via LinkedIn and online channels is also increasing. However, traditional trade fair visits, personal customer appointments and technical workshops for maintaining existing customers and acquiring new customers are just as important to us.”
“Our direct access to the production process allows us to carry out close checks and guarantees consistently high quality.”
Further information:
Focused transducers from SECO Sensor – focused on precision
The focused transducers from SECO Sensor stand for maximum accuracy over long distances. Thanks to the targeted focusing of the sound beam and thus a small beam width, they enable precise measurements from a few centimetres to several meters. These transducers are particularly in demand where precise results are required – for example in industrial automation, level measurement in large containers or when detecting small objects over long distances.
With frequency ranges between 80 and 500 kHz, focused transducers offer high echo voltage and excellent quality. Their design is optimized for robustness and environmental resistance. They retain their full functionality even under difficult external conditions such as dust, fog or dirt.
The focused transducers from SECO Sensor are immediately available, industrially tested and robust – for reliable precision in continuous use.
